4. Select the main menu tab that corresponds to the category of information you want to view
and select the webpage menu from the list.
The webpage content is displayed.
5. Click the webpage content headings to expand and view the meter’s data.
6. Select Setup to view and edit your meter’s configuration.
Embedding images and files in meter webpages
Upload images, documents, audio and video files to meter webpages using SFTP.
NOTE: Images cannot be scaled after they are uploaded. Format images to the desired size
before uploading.
1. Access your meter’s internal SFTP site.
2. Open the web folder. Copy your file into the subfolder that corresponds to the webpage
main menu tab you want to access your file from.
3. Connect to your meter’s webpages. Select the main menu item that corresponds to the
folder you previously selected. Your file is listed in the webpage menu.
4. Select your file from the webpage menu to view it.
Creating custom webpages
Create custom webpages to view data or access configuration parameters from your meter.
Download the meter’s Modbus registers map from www.usa.siemens.com/pds.
1. Open SFTP client software.
2. Go to web > examples. Select samplereadings.html to create a data value webpage or
select sampleconfiguration.html to create a configuration parameters webpage.
3. Save a copy of the sample file. This filename is the webpage name.
4. Open your webpage in an HTML or webpage editor program.
5. Modify the webpage to reference the desired meter data or parameters from the Modbus
registers map, and update the other fields where required.
6. Save your custom webpage.
The meter will display translated content if it exists in the meter’s memory. If translated
content is not available, English is displayed.
7. Connect to your meter’s internal SFTP site.
If you have created a data viewing webpage, copy your custom webpage to web >
monitoring.
If you have created a configuration webpage, copy your custom webpage to web >
setup.
8. Login to your meter’s webpages.
Your custom webpage is available from the webpage menu under the Monitoring (data viewing)
or Setup (configuration) tab.
9810 series - User manual Webpages
7EN05-0390-08 150
