NOTE: The energy pulsing LEDs are configured in pairs. For example, changing the energy
source value will change it for both the regular and infrared LEDs.
NOTE: To modify your default energy source value, go into the advanced mode of ION Setup
and modify the associated Calibration Pulser module. This is an advanced procedure that
should only be performed if you have advanced knowledge of ION and the power system your
meter is connected to.
For more information on the Calibration Pulser module, see ION Reference, available on
www.usa.siemens.com/pds.
For more information on other LED indicators, see "Alarm and status LED indicators" on page
165.
Configuring LED energy pulsing using IONSetup
You can configure your meter’s energy pulsing LEDs for energy pulsing using ION Setup.
1. Start ION Setup.
2. Open the Setup Assistant for your device.
3. Select LED pulsing.
4. Select the tab that corresponds to the energy pulsing LED you want to configure.
5. Configure the following basic parameters for your meter’s energy pulsing LEDs.
Parameter Description
Source Link this input to the value that you want to pulse on the LED.
Enable
Configuring this setting should only be performed by users with advanced
knowledge of ION, the device template and the power system the device is
connected to.
Int Mode
Specifies the integration mode for the LED (forward, reverse, absolute or
net).
Kt The amount of source energy required to make the LED pulse.
Pulse Width The minimum time in seconds between LED pulse transitions.
Pulser Mode
Select when the energy pulsing LEDs will pulse:
•
Always: the energy pulsing LEDs are always pulsing based on their
energy source value.
Pulse ovrld
Pulsing normally indicates that the energy pulsing LED should be operating
normally.
Pulsing suspended indicates that the energy pulsing LED is not able to pulse
quickly enough. Modify the Kt value to decrease the number of energy pulses
or decrease the pulse width, if supported by the device collecting pulses.
Energy pulsing LED parameters available through ION Setup
9810 series - User manual Inputs/Outputs
7EN05-0390-08 144
