1. Start ION Setup.
2. Open the Setup Assistant for your meter.
3. Click Power Quality > Transient Logging.
4. Select the data log and click Edit. Enter the meter password if prompted.
The Transient Logging Wizard appears.
5. The Device setting verification screen displays the results of meter configuration check
for potential errors related to transient monitoring and reporting. Click Fix to view details or
click Next to ignore the results and proceed to the next screen.
6. The Transient Logging Setup screen displays Transient data recorder’s Log Depth
setting. You can change the maximum number of records to store in the Transient data log.
Click Next to proceed to the next screen.
7. The Waveform Log Setup screen allows you to configure the waveform recorder for
Standard or Delayed waveform capture.
NOTE: The Transient Logging Wizard does not support Extended waveform capture. See
“Waveform capture” for details on Standard, Delayed and Extended waveform capture.
Parameter Description
Waveform
Depth
Specifies the maximum number of waveform records stored on the
meter.
Waveform
Format
Specifies the number of samples per cycle and the number of cycles that
are stored in a waveform record.
Trigger
Position
Specifies the number of cycles to capture before the waveform versus
after the waveform. Trigger position can be set using the pre-cycle
arrows or the slider bar.
NOTE: The maximum number of cycles (pre-event + post-event) cannot exceed the total
number of cycles in the waveform format.
Click Next.
8. Configure your meter’s COMTRADE settings:
a. Select or clear the Generate COMTRADE files check box to enable or disable the
creation of COMTRADE records.
NOTE: The waveform viewer on your meter’s webpages uses the meter’s
COMTRADE files. If you want to view waveforms on the meter’s webpages, select
Generate COMTRADE files.
NOTE: The factory-default configuration for COMTRADE only supports Standard
waveform capture.
b. Set the Log depth for the COMTRADE files to specify the maximum number of records
stored on your meter’s internal SFTP site.
