CLINITEK Status+ Analyzer Operator’s Guide 157
Symbols
Data Transfer to
Personal Computer
Displays the individual data and
test results that the
CLINITEK Status+ analyzer transfers
to a PC.
Alert Alerts you to an error message.
Battery Power Displays a maximum of four bars,
indicating the battery power level
of a a battery powered analyzer.
Low Battery Power Displays fewer than three bars,
indicating the battery power level
of a a battery powered analyzer is
low.
Paper Out Displays when you need to replace
the printer paper or label roll.
Connector Indicates that the analyzer is
connected to the CLINITEK Status
connector.
No Connector Displays only if you run a
CLINITEK Status+ analyzer with a
CLINITEK Status connector.
Indicates that the CLINITEK Status+
analyzer is not connected to the
CLINITEK Status connector.
Symbol Name Description
