• Data transmission in relay operation mode (multi-point traffic with routing)
─ Main and Standby Transmission Line
• Functions for supporting redundant communication routes
─ NUC redundancy (Norwegian Users Convention)
− NUC redundancy controlling station
─ 1703 redundancy
− Listening mode with passive
− Tristate of the RS-232 interfce with passive
• Special functions
─ Summer time bit (SU) = 0 for all messages in transmit direction (summer time bit in
time tag)
─ Day of week (DOW) = 0 for all messages in transmit direction (day of week time tag)
─ Originator address = 0 for all messages in transmit direction
5.5.7.2 Operating Modes
Operating mode Interface →
optional DTE
Interface signals
Unbalanced interchange circuit
(V.24/V.28) RS-232 asynchronous
X2 RXD, TXD, CTS
1)
, RTS, DCD, DTR,
DSR/VCC, GND
Balanced interface (V.11) RS-485 (2-wire)/
RS-422 (4-wire) asynchronous
X3 TXD+/RXD+, TXD-/RXD- (2-wire)
TXD+, TXD-, RXD+, RXD- (4-wire)
Balanced interface (V.11) RS-485 (2-wire)/
RS-422 (4-wire) asynchronous
X2 → CM-0829
(CM-0819
2)
)
RXD, TXD, CTS, RTS, DCD, DTR,
DSR/VCC, GND (to CM-08x9)
Optical interface (multimode fibre optic)
ring
X2 → CM-0821 RXD, TXD, CTS, RTS, DCD, DTR,
DSR/VCC, GND (to CM-0821)
Unbalanced interchange circuit
(V.24/V.28) RS-232 asynchronous
X6
3)
RXD, TXD, CTS, RTS, DCD, DTR,
DSR, GND
Balanced interface (V.11) RS-485 (2-wire)/
RS-422 (4-wire) asynchronous
X6
3)
TXD+/RXD+, TXD-/RXD- (2-wire)
TXD+, TXD-, RXD+, RXD- (4-wire)
1)
not usable (reserved for SICAM TOOLBOX II)
2)
RS-422 not supported
3)
only CP-8022 (switchable mode via parameter)
Note
Details about realization of various operation modes are given in the manual SICAM SICAM RTUs Plat-
forms – Configuration Automation Units and Automation Networks.
