Siemens CP-8022

Installation and Circuitry
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 171
DC8-037-2.02, Edition 10.2017
6.2 Dimensions
6.2.1 CP-8000 Front View
6.2.2 CP-8000 Side View
1
2
4
m
m
128 mm
SICAM CMIC
F4F3F2F1
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RTX2
RS-485
OH3
RTX3
ETH
LK4
PK4
SD
X4
SICAM A8000
CP-8000
124 mm
123 mm
116 mm
