Ambient Conditions
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 77
DC8-037-2.02, Edition 10.2017
4.2 Mechanical Ambient Conditions
Parameter Value Test standard Product standard Class
Harmonic
Amplitude of the excursion
1…9 Hz
Acceleration 9…200 Hz
Acceleration 200…500 Hz
±3.0 mm
10 m/s²
15 m/s²
IEC 60068-2-6 IEC 60870-2-2 Bm
Amplitude 10…60 Hz
Acceleration 60…150 Hz
±0.075 mm
1 g
IEC 60068-2-6 IEC 60255-21-1 2
Shock
Acceleration; 11 ms dura-
tion (functional capability)
100 m/s² IEC 60068-2-27 IEC 60870-2-2 Bm
Acceleration; 11 ms dura-
tion (resistivity)
15 g IEC 60068-2-27 IEC 60255-21-2 1
Continuous shock
Acceleration; 16 ms
duration
10 g IEC 60068-2-27 IEC 60255-21-2 1
Seismic harmonic
Amplitude 1…8 Hz
(horizontal)
Amplitude 1…8 Hz
(vertical)
Acceleration 8…35 Hz
(horizontal)
Acceleration 8…35 Hz
(vertical)
±7.5 mm
±3.5 mm
2 g
1 g
IEC 60068-3-3 IEC 60255-21-3 2
The listed values cover or exceed the required seismic loading according to IEC 60870-2-2
Cl.S3 and IEC 60255-21-3 Cl.1. The values apply in operation and for storage.
The permitted mechanical stresses during transport depend on the transport packaging.
The device packaging is not a transport packaging.
