Siemens CP-8022 User Manual

System Components and Technical Data
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 129
DC8-037-2.02, Edition 10.2017
5.5.10.2 Operating Modes
Operating mode Interface →
optional DTE
Interface signals
Electrical Ethernet interface
(twisted pair)
X1
X4
TXD+, TXD-, RXD+, RXD-
Note
Details about realization of various operation modes are given in the manual SICAM RTUs Platforms -
Configuration Automation Units and Automation Networks.
5.5.10.3 Communication
For the communication infrastructure, additional suitable transmission facilities and/or network
components may be needed.
Own Station (Central Station)
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
DNPiT2
Remote Station (Substation)
System System element Protocol element Remarks
SICAM A8000 CP-8000/CPC80
CP-802x/CPC80
DNPiT1
DNPST0
additional serial/Ethernet
converter (device server) is
required
SICAM AK 3 CP-2016/CPCX26
CP-2019/PCCX26
SM-2551/DNPSA0
SM-0551/DNPSA0
additional serial/Ethernet
converter (device server) is
required
Legacy systems
(SICAM AK,
SICAM TM,
SICAM BC, Ax 1703)
CP-20xx
CP-50xx
CP-60xx
SM-2551/DNPSA0
SM-0551/DNPSA0
SM-2541/DNPU00
additional serial/Ethernet
converter (device server) is
required
acc. to SICAM RTUs DNP3
Interoperability
Third-party system – – acc. to SICAM RTUs DNP3
Interoperability
