Siemens CP-8022 User Manual

Engineering via SICAM WEB
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 413
DC8-037-2.02, Edition 10.2017
9.1.13.2.1 Supported Type Identifications and Possible Values
Type Identification Possible value
Single-point information
(TI 30)
Off (0)
On (1)
Double-point information
(TI 31)
Intermediate (00),
Off (01)
On (10)
Error (11)
Single command (TI 45) Off (0)
On (1)
Double command (TI 46) Terminated (00)
Off (01)
On (10)
Error (11)
Tap position command (TI 47) Terminated (00)
Lower (01)
Higher (10)
Error (11)
Counter value (TI 37)
Measured value normalized
(TI 34)
-1…+1
-15
Measured value scaled (TI 35) -32768…+32767 (15 Bit + sign)
Measured value short floating
point (TI 36)
-1.000•10
15
…+1.000•10
15
Setpoint normalized (TI 48) -1…+1
-15
Setpoint scaled (TI 49) -32768…+32767 (15 Bit + sign)
Setpoint short floating point
(TI 50)
-1.000•10
15
…+1.000•10
15
Value from device without conversion
The values are converted depending on the type identification (TI). Analog values are dis-
played as conditioned values.
The data format of the displayed inputs corresponds to the setting of the respective data point
on the I/O Module (signal list).
