Siemens CP-8022

Installation and Circuitry
SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual Unrestricted 231
DC8-037-2.02, Edition 10.2017
6.11.1.5 Dial-up Traffic GSM, SMS Sender/Receiver
Modem Protocol Description
Cinterion MC52iT DIAST0 Data transmission via GSM with CSD-Service (Circuit
Switched Data)
MC Technologies MC55iw SMST0 SMS Sender/Receiver
6.11.1.5.1 CP-8000
Wiring for Modem Cable
Connection CTS–GND: see note at page 212.
F4F3F2F1
POK
RY
ER
ETH
LK1
PK1
RS-232
OH2
RS-485
OH3
ETH
LK4
PK4
SD
X4
CP-8000
8 to 30 VDC
Cinterion MC52iT or
MC55iw Terminal
DCD
RXD
TXD
DTR/5 V
GND
DSR
RTS
CTS
n.c.
GND
RXD
RI
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
DSR
CTS
RTS
DCD
DTR
TXD
GND
V+
IGT_IN
PD_IN
X2:1
X2:2
X2:3
X2:4
X2:5
X2:6
X2:7
X2:8
X2:9
1
2
3
4
5
6
7
8
9
6-pole
RJ12
Shield
Shield
Shield
9-pole D-sub
female
DC 8 V to DC 30 V
