Engineering via SICAM TOOLBOX II
300 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
8.1.9.4 Displaying Decentralized Archive (DEAR)
The current contents of DEAR can be displayed with the tool “OPM II”.
Via the context menu of the automation unit, submenu Display decentral archiving… , you
get to the file directory.
Then select a file and click on the button Display archives to display the respective rec-
ords.
Note
The data records of the decentralized archive are registered in configurable files. The files are stored on
the SD card. The record of data points is therefore only possible with equipped SD card.
Example
You can save the displayed records of DEAR in a file (Format .csv) on the engineering PC.
You find the information thereto in the SICAM TOOLBOX II Online Help, chapter “OPM II”,
section “System Technique”, “General”, “SICAM RTUs”, “Decentral Archive Display”.
