System Components and Technical Data
90 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
5.3 Power Supply Modules
5.3.1 CP-8000 (integrated)
5.3.1.1 Technical Data
Voltage input
Input voltage DC 24…60 V +15%/-25%
*)
+30%/-25%
**)
*)
caused by the connection between input voltage and AUXV0
the input voltage must be < DC 70 V
**)
the reliable function of the power supply is guaranteed up to
DC 78 V
Input power 34 W
Protection type Double insulation
Rated impulse voltage 4 kV
Voltage outputs
Output voltage 1 (internal) DC 5.2 V ±3%
Output voltage 2 (internal) DC 12 V +30/-5%
Output voltage 3 (external) DC 5.2 V
1)
±3%
Output voltage for contact wetting Equals input voltage 3x each 100 mA
2)
Output power 1 2.5 W
Output power 2 3 W
Output power 3 5 W
Guaranteed interruption time 100 ms
Mechanics
Connections Removable screw terminals for direct conductor assembly
cross-section up to 2.5 mm²
1)
not short-circuit proof and not overload proof
2)
protective mechanism is a self resetting fuse (PTC)
statistical values: operation voltage: DC 60 V max.
switching capacity: < 40 A
ohmic resistance: < 5 Ω
permanent floating current after activation of the fuse: < 1.3 A
