Engineering via SICAM WEB
452 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
• Click Select a file in order to open the selection dialog
• Select the source directory and the source file (file type must be cmc, file name including
path name must not exceed 128 characters)
• Click on the button
The target device starts the loading procedure. The duration of the loading procedure de-
pends on the file size and the used communication connection.
Note
During loading procedures the website must not be left. The selection of another website may lead to the
occurrence of undefined states.
Subsequently the file is checked upon integrity. Thereto, a cryptologic hash function is calcu-
lated over the file and the result is compared with the hash value in the filename:
• If the file is valid, the data is written on the SD card of the target device and all settings in
the target device are adapted
• With different results, the file is deleted and no changes are carried out; an error infor-
mation is displayed
After successful upload the target device will be restarted:
• Click on the button in order to close the dialog
