Engineering via SICAM WEB
458 Unrestricted SICAM A8000 / CP-8000 • CP-8021 • CP-8022 Manual
DC8-037-2.02, Edition 10.2017
Note
During generation procedures the website must not be left. The selection of another website may lead to
the occurrence of undefined states.
With the generation of the configuration file the parameters used for SICAM PAS I\O are
checked. With faulty parameterization the following dialog appears:
You have to abort the procedure and correct the parameters, refer to Parameter check.
When the generation of the configuration file has finished, the following dialog appears:
• Click on Start download
The storing procedure may vary dependent on the used web browser and may take some
time, depending on the file size and transmission rate. Follow the instructions of your web
browser. The file name is put together of PASIO_CFG<date>_<time>.xml.
• After successful generation click on in order to close the dialog
