Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 18 PME73.831… 29.11.2011
Parameter
number
Parameter Edit Value range Resolution Factory setting Password level
reading from
level
Password level
writing from level
259.00 Opening time of actuator (timeout) Edit 0 s 1237 s 4.851 s 67.914 s SO OEM
259.01 Opening time of actuator from ignition load to low-fire position Edit 0 s 37.485 s 0.147 s 14.994 s SO OEM
259.02 Opening time of actuator from low-fire to ignition load position Edit 0 s 37.485 s 0.147 s 14.994 s SO OEM
260 Closing time of actuator (timeout) Edit 0 s 1237 s 4.851 s 67.914 s SO OEM
515
Actuator position during prepurge time and postpurge time
0: Purging in low-fire
1: Purging in high-fire
Edit 0 1 1 1 SO OEM
560 Pneumatic combustion control
0 = off/3-step modulation
1 = PWM fan/analog modulation
2 = air damper/analog modulation
(feedback potentiometer ASZxx.3x required)
Edit 0 2 1 0 SO SO
600 Power setting
654 Analog input (feedback potentiometer ASZxx.3x required)
0 = 3-position step input
1 = 0...10 V
2 = 0...135
3 = 0...20 mA
4 = 4...20 mA with lockout at I <4 mA
5 = 4...20 mA
Edit 0 5 1 0 SO SO
