72/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 12 PME71.901... 29.11.2011
Parameter Parameter Edit Value range Resolution Factory setting Password level Password level
number Min. Max. reading from level writing from level
500 Ratio control
503.00 No-flame speeds PWM fan: Standby speed Edit 0 rpm 9000 rpm 10 rpm 0 rpm
SO
SO
503.01 No-flame speeds PWM fan: Purge speed
Edit
800 rpm 9000 rpm 10 rpm 5700 rpm
SO
SO
516.00
Speed limit ignition load P0: Minimum limit
Edit
800 rpm 9000 rpm 10 rpm 800 rpm
SO
OEM
516.01
Speed limit ignition load P0: Maximum limit
Edit
800 rpm 9000 rpm 10 rpm 9000 rpm
SO
OEM
517.00
Speed limit low-fire P1: Minimum limit
Edit
800 rpm 9000 rpm 10 rpm 800 rpm
SO
OEM
517.01
Speed limit low-fire P1: Maximum limit
Edit
800 rpm 9000 rpm 10 rpm 9000 rpm
SO
OEM
518.00
Speed limit high-fire P2: Minimum limit
Edit
800 rpm 9000 rpm 10 rpm 800 rpm
SO
OEM
518.01
Speed limit high-fire P2: Maximum limit
Edit
800 rpm 9000 rpm 10 rpm 9000 rpm
SO
OEM
519
Maximum fan speed
Edit
3000 rpm 9000 rpm 10 rpm 5830 rpm
SO
OEM
522
Ramp-up low-fire ï‚® high-fire
Edit
2.058 s 74.970 s 0.294 s 14,994 s
SO
OEM
523
Ramp-down high-fire ï‚® low-fire
Edit
2.058 s 74.970 s 0.294 s 14,994 s SO
OEM
558
Mode: UDS status information
0 = PC tool mode
1 = PWM mode
2 = actuator mode
3 = internally
4 = internally
5 = internally
Read only 0 5 1 0
SO
---
559
PWM mode
0 = open loop control
1 = PID control
2 = safety mode (PWM limits)
Edit 0 2 1 1
SO
OEM
560
Mode: Pneumatic ratio control
0 = OFF
1 = PWM fan
2 = air damper actuator
Read only 0 2 1 1
SO
---
