73/245
Building Technologies Division Basic Documentation LME7... CC1P7105en
Infrastructure & Cities Sector 12 PME71.901... 29.11.2011
Parameter Parameter Edit Value range Resolution Factory setting Password level Password level
number Min. Max. reading from level writing from level
600 Power setting
644 Number of pulses per revolution Edit 2 5 1 3 SO OEM
646 Settling time for assessment of speed Edit 1.029 s 2.058 s 0.147 s 2,058 s SO OEM
650.00 Speed tolerance band: Speed shutdown Edit 1% 5% 1% 1% SO OEM
650.01 Speed tolerance band: Quick speed shutdown Edit 1% 10% 1% 3% SO OEM
654 Analog input (feedback potentiometer ASZxx.3x required)
0 = 3-position step input
1 = 0...10 V
2 = 0...135
3 = 0...20 mA
4 = 4...20 mA with lockout at I <4 mA
5 = 4...20 mA
Edit 0 5 1 1 SO SO
658.00 PWM values fan: Start PWM Edit 1% 100% 1% 25% SO OEM
658.01 PWM values fan: Min. PWM operating range Edit 0% 20% 1% 0% SO OEM
658.02 PWM values fan: Max. PWM operating range Edit 80% 100% 1% 100% SO OEM
659.00 Ramp time of fan: Min. low-fire to high-fire Read only 0 s 74.970 s 0.294 s 2,058 s SO ---
659.01 Ramp time of fan: Max. low-fire to high-fire Read only 0 s 74,.70 s 0.294 s 74,970 s SO ---
659.02 Ramp time of fan: Min. high-fire to low-fire Read only 0 s 74.970 s 0.294 s 2,058 s SO ---
659.03 Ramp time of fan: Max. high-fire to low-fire Read only 0 s 74.970 s 0.294 s 74,970 s SO ---
660 Tolerance time speed deviation Read only 0 s 37.85 s 0.147 s 4,998 s SO ---
674 Neutral band (permitted control offset) Edit 0 rpm 255 rpm 1 rpm 40 rpm SO OEM
675.00 PWM: Min. PWM with prepurging, SEC Edit 0% 100% 1% 86% SO OEM
675.01 PWM: Max. PWM with ignition load, SEC Edit 0% 100% 1% 34% SO OEM
676 Gain factor speed control Read only 0 255 1 112 SO ---
677 Integral action time speed control Read only 0 s 37.485 s 0.147 s 0,441 s SO ---
678 Derivative action time speed control Read only 0 s 37.485 s 0.147 s 0 s SO ---
679.00 Time constant PT1 speed control: Lower speed range high-fire to low-
fire
Edit 0 s 37.485 s 0.147 s 6,027 s SO OEM
679.01 Time constant PT1 speed control: Medium speed range high-fire to
low-fire
Edit 0 s 37.485 s 0.147 s 6,027 s SO OEM
679.02 Time constant PT1 speed control: Upper speed range high-fire to low-
fire
Edit 0 s 37.485 s 0.147 s 6,027 s SO OEM
679.03 Time constant PT1 speed control: Total speed range low-fire to high-
fire
Edit 0 s 37.485 s 0.147 s 6,027 s SO OEM
680.00 Speed range for PT1 time constant: Threshold upper speed range Edit 800 rpm 9000 rpm 10 rpm 4000 rpm SO OEM
680.01 Speed range for PT1 time constant: Threshold lower speed range Edit 800 rpm 9000 rpm 10 rpm 2000 rpm SO OEM
