Siemens Milltronics BW500/L - ECal Parameters (P693 - P698)

Parameters
12.10 ECal Parameters (P693 – P698)
BW500 and BW500/L
184 Operating Instructions, 12/2016, A5E33482052-AD
12.9.15
P691 Drive Pulley Diameter
For speed constant entry (P690 =2), this parameter is enabled for entry of the drive pulley
diameter (P691-01 or 02)
1)
.
Enter the pulley diameter (units determined in P004).
1)
BW500/L has only one speed input
12.9.16
P692 Pulses Per Sensor Revolution
For speed constant entry (P690 = 2), this parameter is enabled for entry of the pulses per
revolution that the speed sensor delivers (P692-01 or 02)
1)
.
Enter the pulses per revolution from the speed sensor nameplate.
1)
BW500/L has only one speed input
12.10
ECal Parameters (P693 – P698)
Accessible only through P017 for ECal test reference. After Ecal completion, only a zero
calibration is necessary to allow access to the
RUN
mode.
Note
ECal is not available on six load cell belt scales.
12.10.1
P693 Load Cell Capacity Units
Determines the units used for entering eCal data:
1 = kg
2 = lb
3 = Other (mV Span)
1)
1)
In the case of other, software jumps to P699 since data entry P694 through P698 are not
applicable if P693=4.
12.10.2
P694 ECal Load Cell Capacity
Enters the load cell’s weighing capacity for the selected cell ( f = 1.0).
-01 = load cell A
-02 = load cell B
-03 = load cell C
2)
-04 = load cell D
2)
Enter the value in the units corresponding to the scale selection, e.g. in kg if P693 = 1, or lb. if
P693 = 2 or 3.
2)
Not available with BW500/L
