Byte Bit Data format Soft starter diagnostics Error types 3RW
F
5)
+ F
6)
50
1)
52
2)
55
3)
55-F
4)
31 0 Bool Switching element cooling time active - - r r r r
1 Bool Switching element too hot for Start 0x1083 - r r r r
2 Bool Current measuring range exceeded 0x0007 x r r r r
32 0 Bool Automatic mode - - r r r r
1 Bool Operating mode manual - - r r r r
2 Bool Manual operation bus - PC controlled - - r r r r
3 Bool Operating mode manual - local - - r r r r
4 Bool Manual operation local - input controlled - - r r r r
5 Bool Manual operation local - HMI controlled - - r r r r
6 Bool Manual operation local - PC controlled - - r r r r
33 0 Bool Manual operation bus - Webserver controlled - - - - r
12)
r
11)
3 Bool Automatic operation - input controlled - - - - r
10)
r
11)
35 0 Bool Device error - - r r r r
38 0 Bool FW update rejected - - r r r r
1 Bool FW update active - - r r r r
2 Bool FW update successful - - r r r r
3 Bool FW update faulty 0x011B - r r r r
39 7 Bool Operation / bypass active - - r r r r
46 6 Bool Start pause pending - - - - r
10)
r
7 Bool Energy saving mode active - - - - r
10)
r
52 6 Bool Normal operation active - - r r
7)
r r
53 3 Bool Test mode active - - r r
7)
r r
59 0 Bool Start condition not ful󹪝lled - - - - - r
1 Bool Start condition ful󹪝lled - - - - - r
2 Bool Reset ON command required - - - - - r
60 0 Bool EX application active - - - - r
9)
r
2 Bool New Ex parameter values detected 0x1036 - - - r
9)
r
5 Bool Ex release denied - wrong CRC - - - - r
9)
r
62 2 Bool Remaining time for tripping warning limit under‐
shot
0x1089 - - - r r
3 Bool Motor heating warning limit exceeded 0x1022 - r r r r
4 Bool Current limit - maintenance demanded exceeded 0x1040 - - - r r
5 Bool Current limit - maintenance demanded under‐
shot
0x1041 - - - r r
6 Bool Asymmetry limit warning exceeded 0x1021 - - - r r
7 Bool Ground fault limit warning exceeded 0x1027 - - - r r
65 0 Bool Pump cleaning active - - - - r r
66 5 Bool Analog output under󹪞ow - - - - r r
67 5 Bool Analog output over󹪞ow - - - - r r
70 0 Bool Missing initialization after maintenance - - r r r r
Appendix
A.4 Data sets
SIRIUS 3RW5 PROFINET communication modules
Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004 171
