Byte Bit Data format Soft starter diagnostics Error types 3RW
F
5)
+ F
6)
50
1)
52
2)
55
3)
55-F
4)
19 0 Bool Self-test active - - - - r r
2 Bool Self-test error 0x1080 - r r r r
3 Bool Factory settings restored - - r r r r
20 0 Unsigned16 Faulty parameter number
8)
- - - - r r
22 3 Bool Preset unequal actual con󹪝guration 0x1094 - r r r r
5 Bool Temperature sensor overload 0x1024 - - - r r
6 Bool Temperature sensor wire break 0x1026 - - - r r
7 Bool Temperature sensor short-circuit 0x1025 - - - r r
23 0 Bool Parameter set 1 active - - - - r r
1 Bool Parameter set 2 active - - - - r r
2 Bool Parameter set 3 active - - - - r r
4 Bool Parameter set change not possible - - - - r r
6 Bool Preset unequal actual con󹪝guration 0x1094 - - - r r
7 Bool Motor connection wrong 0x1092 x - - r r
24 2 Bool Motor heating active - - - - r -
3 Bool DC braking active - - - - r -
4 Bool Dynamic DC braking active - - - - r -
5 Bool Type of motor connection standard - - r r r r
6 Bool Type of motor connection inside delta - - - r r r
7 Bool Type of motor connection unknown - - r r r r
25 0 Bool Missing load 0x1000 x r r r r
2 Bool Loss of phase L1 0x1097 x r r r r
3 Bool Loss of phase L2 0x1097 x r r r r
4 Bool Loss of phase L3 0x1097 x r r r r
5 Bool Main power rotation right - - r r r r
6 Bool Main power rotation left - - r r r r
27 0 Bool Output 1 active - - r r r r
1 Bool Output 2 active - - r r r r
2 Bool Output 3 active - - r r r r
3 Bool Output 4 active - - - - r r
4 Bool Output 1 - Time active - - - - r r
5 Bool Output 2 - Time active - - - - r r
7 Bool Output 4 - Time active - - - - r -
29 1 Bool Ready to start for motor ON - - r r r r
3 Bool Bypass defective 0x1081 x r r r r
4 Bool Bypass protective shuto󹪜 0x1085 x r r r r
5 Bool Switching element L1 failed 0x1082 x r r r r
6 Bool Switching element L2 failed 0x1082 x - r r r
7 Bool Switching element L3 failed 0x1082 x r r r r
30 0 Bool Thermal motor model deactivated - - r r r r
3 Bool Phase control failure 0x1012 x r r r r
