Siemens PROFINET SIRIUS 3RW5 - Page 189

Object
No.
Byte Bit Data format Parameters Value range
[encoding]
Incre‐
ment
3RW
50 / 52
1)
[D
3)
]
55 /
55‑F
2)
[D
3)
]
2295 190 0 Bit4 Bypass operation mode
9)
[1 ... 4] - r
6), 11)
[1]
r/w
4), 8), 10)
[1]
[1] Internal bypass
[2] External bypass with‐
out current measurement
[4] No bypass
2310 191 0 Bit4 Parameters of CPU/
master disabled
9)
[1 ... 3] - - r/w
[1]
[1] Deactivate
[2] Activate
[3] Activate for start-up
parameters only
2311 192 0 Bit4 Soft torque
9)
[0 ... 1] - r
[0]
-
[0] Deactivate
[1] Activate
2313 193 0 Bit4 Automatic parameteriza‐
tion
[0 ... 2] - - r/w
[0]
[0] O󹪜
[1] ON - with preset start‐
ing time
[2] ON - with preset start‐
ing time and current limit
2315 194 0 Unsigned16 Preset starting time 0 … 360 s
[0 … 3 600]
0.1 s - r/w
[100]
2332 196 0 Unsigned8 Alternative dynamic
braking torque
9)
20 … 100 %
[4 … 20]
5 % - r/w
8)
[10]
2331 197 0 Unsigned8 Alternative DC braking
torque
9)
20 … 100 %
[4 … 20]
5 % - r/w
8)
[10]
- 198 ...
199
0 - Reserved - - - -
1)
Supported by SIRIUS 3RW50 and 3RW52 soft starters
2)
Supported by SIRIUS 3RW55 and 3RW55 Failsafe soft starters
3)
Default encoding
4)
Parameter is relevant for EX applications
5)
Not supported by SIRIUS 3RW52 soft starter
6)
Not supported by SIRIUS 3RW50 soft starter
7)
Not supported by SIRIUS 3RW55 soft starter
8)
Not supported by SIRIUS 3RW55 Failsafe soft starter
9)
Parameter is only available in data set 131
10)
3RW55 soft starter from 󹪝rmware version V2.0 or 3RW55 Failsafe soft starter from 󹪝rmware version V1.0
11)
3RW52 soft starter from 󹪝rmware version V2.0
Appendix
A.4 Data sets
SIRIUS 3RW5 PROFINET communication modules
Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004 189
