Object
No.
Byte Bit Data format Parameters Value range
[encoding]
Incre‐
ment
3RW
50 / 52
1)
[D
3)
]
55 /
55‑F
2)
[D
3)
]
2209 140 0 Bit4 Ex application
9)
[0 ... 3] - - r/w
4), 10)
[0]
[0] No
[1] Yes, with complete
motor protection
[2] Yes, with thermal mo‐
tor model
[3] Yes, with PTC temper‐
ature protection
2327 142 0 Unsigned16 Alternative stopping
time
9)
0 … 360 s
[0 … 3 600]
0.1 s - r/w
[100]
235 144 0 Unsigned16 Current limiting value 125 … 800 %
[125 … 800]
1 % r
[400]
r/w
[400]
2212 146 0 Unsigned8 Service factor 1 … 1.15
[100 … 115]
0.01 - r/w
4)
[100]
2210 148 0 Unsigned8 Motor heating warning
limit
9)
0 … 99 %
[0 … 99]
1 % - r/w
[0]
[0] Deactivated
2211 150 0 Unsigned16 Remaining time for trip‐
ping warning limit
9)
0 … 500 s
[0 … 500]
1 s - r/w
[0]
[0] Deactivated
2218 157 0 Bit4 Asymmetry limit warn‐
ing
9)
10 … 60 %
[2 … 12]
5 % - r/w
[0]
[0] Deactivated
2220 158 0 Unsigned8 Ground fault limit warn‐
ing
9)
10 … 95 %
[2 … 19]
5 % - r/w
[0]
[0] Deactivated
2359 160 0 Unsigned16 DC braking delay
9)
0 ... 360 s
[0 ... 3 600]
0.1 s - r/w
8), 10)
[0]
2360 162 0 Unsigned16 Alternative DC braking
delay
9)
0 ... 360 s
[0 ... 3 600]
0.1 s - r/w
8), 10)
[0]
2294 168 0 Unsigned8 Ground fault limit error
9)
10 … 95 %
[2 … 19]
5 % - r/w
[4]
[0] Deactivated
2329 169 0 Unsigned8 Alternative stopping tor‐
que
9)
10 … 100 %
[2 … 20]
5 % - r/w
[2]
2333 170 0 Unsigned16 Output 1 - OFF delay
9)
0 … 6 500 s
[0 … 65 000]
0.1 s - r/w
[0]
2334 172 0 Unsigned16 Output 2 - OFF delay
9)
0 … 6 500 s
[0 … 65 000]
0.1 s - r/w
[0]
2336 176 0 Unsigned16 Output 4 - OFF delay
9)
0 … 6 500 s
[0 … 65 000]
0.1 s - r/w
8)
[0]
2352 184 0 Unsigned16 Current limiting value -
maximum
125 ... 800 %
[125 ... 800]
1 % - r/w
[400]
