Error types
Depending on the 3RW5 soft starter, the following error types can be transmitted. You will 󹪝nd
information on recti󹪝cation and acknowledgment of faults and warnings in the Equipment
Manual of the 3RW5 soft starter. Information on which faults and warnings are supported by
the 3RW5 soft starter can also be found in data set 92 of the 3RW5 soft starter (slot 2)
(Page 168).
Error type Inter‐
rupt
type
Error / Warning Cause + F
1)
Byte.Bit
2)
0x0007 ER Upper limit exceeded
• With sensors: The measured value has excee‐
ded the range limits.
• With actuators: The output value has exceeded
an upper limit.
x 31.2
0x0019 ER Safety-related shuto󹪜 The module has detected a problem on the channel
and has therefore executed a safety-related shut‐
o󹪜. The possible reason is a discrepancy error.
x 12.7
0x010A ER No supply voltage
• The power switch is open or the power supply is
not correctly connected.
• No current.
x 11.1
87.1
0x011B ER Invalid/inconsistent 󹪝rm‐
ware present
The 󹪝rmware is incomplete and/or the 󹪝rmware ex‐
pansions are incomplete or incompatible.
- 38.3
0x1000 ER Residual current after ON
command
No current 󹪞ow is detected in the motor feeder af‐
ter an ON command.
• Main circuit is interrupted (fuse, motor starter
protector).
• Motor contactor or contactor control is defec‐
tive.
• The parameter "Execution time" is too short.
• No load.
x 25.0
0x100A ER Test mode current 󹪞ow
• Current is 󹪞owing in the motor feeder although
the motor feeder is in test mode or the test po‐
sition (TPF).
• The main circuit is not interrupted in test mode.
x 87.0
0x1011 MT Generator operation The motor is coasting down. The motor cables may
be energized.
- 13.6
0x1012 ER Phase control failure The fault occurs without the motor starting:
• Motor terminals are incorrectly connected.
• Error in con󹪝guration of inside-delta circuit.
• There is a ground fault.
The fault occurs during starting:
• Chosen starting voltage too high.
• Breakaway pulse wrongly set.
x 30.3
0x1013 MT 2-phase control active
3)
During 3-phase operation, only 2 phases are con‐
trolled, as one pair of thyristors is defective.
- 73.0
Messages and diagnostics
7.2 Diagnostics via con󹪝guration software of the controller
SIRIUS 3RW5 PROFINET communication modules
74 Equipment Manual, 05/2021, A5E35631297002A/RS-AD/004
