Enclosure for ET 200iSP in Zone 2
The ET 200iSP must be installed in an enclosure with at least IP54 degree of protection certi󹪝ed
for Zone 2 (according to EN 60079-7). See Appendix "Article numbers (Page 419)".
&ODMPTVSF
;POF`
$BCMFHMBOE$BCMFHMBOE
*OQVUBOEPVUQVU1PXFS
TVQQMZ
130'*#64
%1&YJ
*1
&YJ
Figure 5-3 Enclosure for ET 200iSP in Zone 2
Enclosure for ET 200iSP in Zone 22
The ET 200iSP must be installed in a dust-protected enclosure with degree of protection IP5X
(according to directive 2014/34/EU for category 3D). Further requirements (surface
temperature, for example) can be found in the certi󹪝cation document for the enclosure. See
Appendix "Article numbers (Page 419)".
Remove dust deposits from the enclosure and its immediate environment at regular intervals; in
other words, always install the enclosure in a location with easy access for cleaning.
Installing
5.1 Installation rules
ET 200iSP
104 Operating Instructions, 11/2022, A5E00247483-AK
