Figure 5-4 Enclosure for ET 200iSP in Zone 22

Enclosure for ET 200iSP in the safe area

The ET 200iSP must be installed in an enclosure with degree of protection IP20.

Mounting position

The ideal installation position is horizontal on a vertical surface. Any other installation position

is also possible; however, there are limitations with regard to ambient temperature.

Installing

5.1 Installation rules

ET 200iSP

Operating Instructions, 11/2022, A5E00247483-AK 105
