Measuring ranges for resistance thermometers Ni 100 climate
Table 14-18 SIMATIC S7 format: Measuring ranges Ni 100 climate in °C and °F
Ni 100 cli‐
mate in
°C(1 digit =
0.01 °C)
Units Ni 100 cli‐
mate in
°F(1 digit =
0.01 °F)
Units Range
Decimal Hexa‐
decimal
Decimal Hexa‐
decimal
> 295.00 32767 7FFF
H
> 325.11 32767 7FFF
H
Over󹪞ow
295.00
:
250.01
29500
:
25001
733C
H
:
61A9
H
327.66
:
280.01
32766
:
28001
7FFE
H
:
6D61
H
Overrange
250.00
:
-60.00
25000
:
-6000
61A8
H
:
E890
H
280.00
:
-76.00
28000
:
-7600
6D60
H
:
E250
H
Nominal range
-60.01
:
-105.00
-6001
:
-10500
E88F
H
:
D6FC
H
-76.01
:
-157.00
-7601
:
-15700
E24F
H
:
C2AC
H
Underrange
< -105.00 -32768 8000
H
< -157.00 -32768 8000
H
Under󹪞ow
Measuring range for thermocouple: Type B
Table 14-19 SIMATIC S7 format: Measuring range type B in °C and °F
Type B in °C Units Type B in °F Units Range
Decimal Hexa‐
decimal
Decimal Hexa‐
decimal
> 2070.0 32767 7FFF
H
> 3276.6 32767 7FFF
H
Over󹪞ow
2070.0
:
1820.1
20700
:
18201
50DC
H
:
4719
H
3276.6
:
2786.6
32766
:
27866
7FFE
H
:
6CDA
H
Overrange
1820.0
:
0.0
18200
:
0
4718
H
:
0000
H
2786.5
:
32
27865
:
320
6CD9
H
:
0140
H
Nominal range
-0.1
:
-120.0
-1
:
-1200
FFFF
H
:
FB50
H
31.9
:
-184.0
319
:
-1840
013F
H
:
F8D0
H
Underrange
< -120.0 -32768 8000
H
< -184.0 -32768 8000
H
Under󹪞ow
Analog electronic modules
14.8 Representation of analog values
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 381
