Measuring range for thermocouple type E
Table 14-20 SIMATIC S7 format: Measuring range type E in °C and °F
Type E in °C Units Type E in °F Units Range
Decimal Hexadec‐
imal
Decimal Hexa‐
decimal
> 1200.0 32767 7FFF
H
> 2192.0 32767 7FFF
H
Over󹪞ow
1200.0
:
1000.1
12000
:
10001
2EE0
H
:
2711
H
2192.0
:
1832.1
21920
:
18321
55A0
H
:
4791
H
Overrange
1000.0
:
-270.0
10000
:
-2700
2710
H
:
F574
H
1832.0
:
-454.0
18320
:
-4540
4790
H
:
EE44
H
Nominal range
< -270.0 - 32768 8000
H
< -454.0 - 32768 8000
H
Under󹪞ow
Measuring range for thermocouple type J
Table 14-21 SIMATIC S7 format: Measuring range type J in °C and °F
Type J in °C Units Type J in °F Units Range
Decimal Hexadec‐
imal
Decimal Hexa‐
decimal
> 1450.0 32767 7FFF
H
> 2642.0 32767 7FFF
H
Over󹪞ow
1450.0
:
1200.1
14500
:
12010
38A4
H
:
2EEA
H
2642.0
:
2192.1
26420
:
21921
6734
H
:
55A1
H
Overrange
1200.0
:
-210.0
12000
:
-2100
2EE0
H
:
F7CC
H
2192.0
:
-346.0
21920
:
-3460
55A0
H
:
F27C
H
Nominal range
< -210.0 - 32768 8000
H
< -346.0 - 32768 8000
H
Under󹪞ow
Measuring range for thermocouple type K
Table 14-22 SIMATIC S7 format: Measuring range type K in °C and °F
Type K in °C Units Type K in °F Units Range
Decimal Hexadec‐
imal
Decimal Hexa‐
decimal
> 1622.0 32767 7FFF
H
> 2951.6 32767 7FFF
H
Over󹪞ow
1622.0
:
1372.1
16220
:
13721
3F5C
H
:
3599
H
2951.6
:
2501.7
29516
:
25062
734C
H
:
61B9
H
Overrange
Analog electronic modules
14.8 Representation of analog values
ET 200iSP
382 Operating Instructions, 11/2022, A5E00247483-AK
