Type K in °C Units Type K in °F Units Range
Decimal Hexadec‐
imal
Decimal Hexa‐
decimal
1372.0
:
-270.0
13720
:
-2700
3598
H
:
F574
H
2501.6
:
-454.0
25061
:
-4540
61B8
H
:
EE44
H
Nominal range
< -270.0 - 32768 8000
H
< -454.0 - 32768 8000
H
Under󹪞ow
Measuring range for thermocouple type L
Table 14-23 SIMATIC S7 format: Measuring range type L in °C and °F
Type L in °C Units Type L in °F Units Range
Decimal Hexa‐
decimal
Decimal Hexa‐
decimal
> 1150.0 32767 7FFF
H
> 2102.0 32767 7FFF
H
Over󹪞ow
1150.0
:
900.1
11500
:
9001
2CEC
H
:
2329
H
2102.0
:
1652.1
21020
:
16521
521C
H
:
4089
H
Overrange
900.0
:
-200.0
9000
:
-2000
2328
H
:
F830
H
1652.0
:
-328.0
16520
:
-3280
4088
H
:
F330
H
Nominal range
< -200.0 -32768 8000
H
< -328.0 -32768 80000
H
Under󹪞ow
Measuring range for thermocouple type N
Table 14-24 SIMATIC S7 format: Measuring range type N in °C and °F
Type N in °C Units Type N in °F Units Range
Decimal Hexadec‐
imal
Decimal Hexa‐
decimal
> 1550.0 32767 7FFF
H
> 2822.0 32767 7FFF
H
Over󹪞ow
1550.0
:
1300.1
15500
:
13001
3C8C
H
:
32C9
H
2822.0
:
2372.1
28220
:
23721
6E3C
H
:
5CA9
H
Overrange
1300.0
:
-270.0
13000
:
-2700
32C8
H
:
F574
H
2372.0
:
-454.0
23720
:
-4540
5CA8
H
:
EE44
H
Nominal range
< -270.0 -32768 8000
H
-32768 8000
H
<EE44
H
Under󹪞ow
