Designation Quantity Article number
Wall box for Zone 21/22 degree of protection IP65; stain‐
less steel; foldable box cover; 3 rows of cable inlets M16
(41 pcs at 650 mm wide 68 pcs at 950 mm wide) and 2
rows of blanking plugs
Empty enclosure prepared:
• 650x450x230 suitable for max. 15 electronic mod‐
ules
• 950x450x230 suitable for max. 25 electronic mod‐
ules
With installation and interconnection of
the ET 200iSP in the wall box
1
:
• 650x450x230 suitable for max. 15 electronic mod‐
ules
• 950x450x230 suitable for max. 25 electronic mod‐
ules
1 unit
6DL2804-0DD30
6DL2804-0DE30
6DL2804-1DD30
6DL2804-1DE30
Wall box for Zone 21/22 degree of protection IP65; stain‐
less steel; hinged enclosure cover; 5 rows cable entries
M16=max. Components (66 pcs. for 650 mm width and
111 pcs. for 950 mm width)
Empty enclosure prepared:
• 650x450x230 suitable for max. 15 electronic mod‐
ules
• 950x450x230 suitable for max. 25 electronic mod‐
ules
With installation and interconnection of
the ET 200iSP in the wall box
1
:
• 650x450x230 suitable for max. 15 electronic mod‐
ules
• 950x450x230 suitable for max. 25 electronic mod‐
ules
1 unit
6DL2804-0DD50
6DL2804-0DE50
6DL2804-1DD50
6DL2804-1DE50
1
The components of the ET 200iSP are not included. These must be ordered and purchased separately.
Network components
The following table lists all network components required for the use of the ET 200iSP.
Note
Bus cable
The recommended bus cable serves as a reference and is not mandatory. However, the cable you
use must match the characteristic values of this cable (e.g. capacity, inductance).
Appendix
A.1 Article numbers
ET 200iSP
Operating Instructions, 11/2022, A5E00247483-AK 423
