Siemens SIMOCODE pro Function Manual

Tables, data records
3.2 Assignment of cyclic receive and send data for predefined control functions
SIMOCODE pro - Communication
128 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.2
Assignment of cyclic receive and send data for predefined control
functions
3.2.1
Overload relay
Table 3- 4 Assignment of cyclic receive / send data, overload relay
Cycl. receive data
Bit 0.0
Not connected
Bit 0.1
Not connected
Bit 0.2
Not connected
Bit 0.3
Further function blocks → Standard functions → Test / Reset → Test1 - Input
Bit 0.4
Further function blocks → Standard functions → Emergency start → Emergency start - Input
Bit 0.5
Not connected
Bit 0.6
Further function blocks → Standard functions → Test / Reset → Reset1 - Input
Bit 0.7
Not connected
Bit 1.0
Not connected
Bit 1.1
Not connected
Bit 1.2
Not connected
Bit 1.3
Not connected
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 *) (analog value)
Not connected
Cycl. send data
Bit 0.0
Not connected
Bit 0.1
Not connected
Bit 0.2
Not connected
Bit 0.3
Event - Prewarning overload (I>115 %)
Bit 0.4
Not connected
Bit 0.5
Not connected
Bit 0.6
Status - General fault
Bit 0.7
Status - general warning
Bit 1.0
Not connected
Bit 1.1
Not connected
Bit 1.2
Not connected
Bit 1.3
Not connected
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 (analog value)
Maximum current I_max
Byte 4/5 *) (analog value)
Not connected
Byte 6/7 *) (analog value)
Not connected
Byte 8/9 *) (analog value)
Not connected
*) for SIMOCODE pro V / pro S, basic type 1 only
