Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
327
3.6.5
Connection Manager object
The following information applies to the Connection Manager object of the SIMOCODE pro V
EtherNet/IP device:
● Class code: 0x06
● Class attributes: 0
● Number of instances: 1
The instance attributes are defined according to Volume 1 of the CIP Specification.
All instance attributes that are defined as "required" in this specification are supported.
Table 3- 92
General services for the Connection Manager object
Service code
Available service
Service designation
Description
Class
Instance
0x0E
No
Yes
Get_Attribute_Single
Supplies contents of one attribute
0x10
No
Yes
Set_Attribute_Single
Changes an attribute value
