Siemens SIMOCODE pro - Dahlander Reversing Starter

Tables, data records
3.2 Assignment of cyclic receive and send data for predefined control functions
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
135
3.2.8
Dahlander reversing starter
Table 3- 11 Assignment of cyclic receive / send data, Dahlander reversing starter
Cyclic receive data
Bit 0.0 Device parameters → Motor control → Control stations → PLC/PCS [DP] → ON >>
Bit 0.1
Device parameters → Motor control → Control stations → PLC/PCS [DP] → OFF
Bit 0.2 Device parameters → Motor control → Control stations → PLC/PCS [DP] → ON >
Bit 0.3
Further function blocks → Standard functions → Test / Reset → Test1 - Input
Bit 0.4
Further function blocks → Standard functions → Emergency start → Emergency start - Input
Bit 0.5
Device parameters → Motor control → Control stations → Mode selector S1
Bit 0.6
Further function blocks → Standard functions → Test / Reset → Reset 1 - Input
Bit 0.7
Not connected
Bit 1.0
Device parameters → Motor control → Control stations → PLC/PCS [DP] → ON <<
Bit 1.1
Not connected
Bit 1.2
Device parameters → Motor control → Control stations → PLC/PCS [DP] → ON <
Bit 1.3
Not connected
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 *) (analog value)
Not connected
Cyclic send data
Bit 0.0
Status - ON>>
Bit 0.1 Status - Off
Bit 0.2
Status - ON>
Bit 0.3
Event - Prewarning overload (I>115 %)
Bit 0.4
Status - Change-over pause active
Bit 0.5
Status - Remote mode
Bit 0.6
Status - General fault
Bit 0.7 Status - General warning
Bit 1.0
Status - ON<<
Bit 1.1
Not connected
Bit 1.2
Status - ON<
Bit 1.3
Status - Interlocking time active
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 (analog value)
Maximum current I_max
Byte 4/5 *) (analog value)
Not connected
Byte 6/7 *) (analog value)
Not connected
Byte 8/9 *) (analog value)
Not connected
*) for SIMOCODE pro V / pro S, basic type 1 only
