Siemens SIMOCODE pro Function Manual

Communication
2.1 PROFIBUS communication
SIMOCODE pro - Communication
28 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
2.1.5
Integration of SIMOCODE pro in DP master systems
2.1.5.1
Slave operating modes
The following table shows an overview of the slave operating modes with which SIMOCODE
pro can be operated on the class 1 master:
Table 2- 8 Slave operating modes of SIMOCODE pro
SIMOCODE pro
integrated as
Class 1 master
Non-vendor-specific DP master,
without DPV1 interrupts
Non-vendor-specific DP
master, with DPV1 interrupts
S7 master
DPV1 slave via GSD
• Cyclic data exchange
• Standard diagnostics
• Status information
• Parameterization during
starting (SIMOCODE pro C
basic unit only)
• Acyclic writing and reading of
DPV1 data records
(if supported by the master)
• Cyclic data exchange
• Standard diagnostics
• Status information
• Hardware and diagnostic
interrupts
• Parameterization during
starting
(SIMOCODE pro C basic
unit only)
• Acyclic reading and writing
of DPV1 data records
• Cyclic data exchange
• Standard diagnostics
• Status information
• Hardware and diagnostic
interrupts
• Parameterization during
starting
(SIMOCODE pro C basic
unit only)
• Acyclic reading and
writing of DPV1 data
records
S7 slave via
OM SIMOCODE pro
— —
• Cyclic data exchange
• Standard diagnostics
• Hardware and diagnostic
interrupts
• Parameterization during
startup
• Acyclic reading and
writing of DPV1 data
records
2.1.5.2
Preparing the data transfer
The precondition for communication with a master class 1 (PLC) is integration according to
table "Slave modes of SIMOCODE pro" and the setting for the PROFIBUS DP address.
You will find information about setting the address in Chapter "Setting the PROFIBUS DP
address" in Chapter "Commissioning and service" in the system manual.

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
