Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
163
3.3.2.5
Data record 69 - Process image input
Table 3- 27 Data record 69 - Process image input
Byte.
Bit
Designation
Default
(also see parameters)
Type
Information
0.0
Cyclic send - Bit 0.0
Status - ON<
Bit
BU0 BU1 BU2(+)
0.1
Cyclic send - Bit 0.1
Status - Off
Bit
0.2
Cyclic send - Bit 0.2
Status - ON>
Bit
0.3 Cyclic send - Bit 0.3 Event - Overload
operation
Bit
0.4 Cyclic send - Bit 0.4 Status - Interlocking
time active
Bit
0.5
Cyclic send - Bit 0.5
Status - Remote mode
Bit
0.6
Cyclic send - Bit 0.6
Status - General fault
Bit
0.7 Cyclic send - Bit 0.7 Status - general
warning
Bit
1.0
Cyclic send - Bit 1.0
Not assigned
Bit
1.1
Cyclic send - Bit 1.1
Not assigned
Bit
1.2
Cyclic send - Bit 1.2
Not assigned
Bit
1.3
Cyclic send - Bit 1.3
Not assigned
Bit
1.4
Cyclic send - Bit 1.4
Not assigned
Bit
1.5
Cyclic send - Bit 1.5
Not assigned
Bit
1.6
Cyclic send - Bit 1.6
Not assigned
Bit
1.7
Cyclic send - Bit 1.7
Not assigned
Bit
2.0 PLC/PCS analog Input 1 PLC / PCS
analog FI
input 1
Max. current I_max Word Float BU0 , BU1,
BU2(+)
BU2+
4.0
PLC/PCS analog input 2
Not assigned
Word
BU0, BU2(+)
6.0 PLC/PCS analog input 3 PLC / PCS
analog FI
input 2
Not assigned Word Float
8.0 PLC/PCS analog input 4 Not assigned Word
