Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
228 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.4.2.5
Data record 72 - Error buffer
Table 3- 56 Data record 72 - Error buffer
Byte.Bit
Entry
Designation
Type
Information
0.0
1
Time stamp
D-word
4.0
Type
Byte
5.0
Error number
Byte
6.0 2 Time stamp D-word
10.0
Type
Byte
11.0
Error number
Byte
...
120.0
21
Time stamp
D-word
124.0
Type
Byte
125.0
Error number
Byte
Time stamp
The operating hours of the device are used as a time stamp (resolution: 1 s).
Type/error number
You will find the mean in Chapter Data record 92 - Device diagnostics (Page 229) in column
"Error number" of table "Data record 92 - Device diagnostics."
If the type has the value 255, the entry displays "Power - On". In this case, the error number
contains the number of power ON operations, reduced by 1 (0 = 1x power ON, ...).
3.4.2.6
Data record 73 - Event memory
Table 3- 57 Data record 73 - Event memory
Byte.Bit
Entry
Designation
Type
Information
0.0
1
Time stamp
D-word
4.0
Entry - Type
Byte
5.0
Entry - Info
Byte[3]
8.0
2
Time stamp
D-word
12.0
Entry - Type
Byte
13.0
Entry - Info
Byte[3]
16.0
3
Time stamp
D-word
20.0
Entry - Type
Byte
21.0
Entry - Info
Byte[3]
...
160.0 21 Time stamp D-word
164.0
Entry - Type
Byte
165.0
Entry - Info
Byte[3]
