3.5 Modbus data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
291
3.5.2.8
Trace data
Read-only access to the trace data is possible via function codes 03 and 04.
Max. data length per access: 63 registers.
Table 3- 79 Trace data
Input/holding register
Identifier
Type
Range
Access
1)
Address
high/low byte; bit
position
Bit
0x2A80 StartPos Word 0 r
0x2A81
high
Channel No.
Byte
0 ... 59
r
low 0 Trace status - Trace
recording in progress
Bit 0, 1 r
1 Trace status - Trigger event
occurred
Bit 0, 1 r
2-7
Reserved
Bit[6]
0
r
0x2A82
Measured value (0)
Word
0 ... 65535
r
0x2A83
Measured value (1)
Word
0 ... 65535
r
...
...
Word
0 ... 65535
r
0x2ABD
Measured value (59)
Word
0 ... 65535
r
1) r/w: Value is read/write; r: Value is read-only
