Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
160 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.3.2.2
Data record 0/1 - S7 system diagnostics
Table 3- 24 Data record 0/1 S7 system diagnostics
Byte.Bit
DR0
DS1
Designation
Type
No error
Error
Information
0.0
X
X
Module fault / OK
Bit
0
1
0.1
X
X
Internal fault
Bit
0
0
0.2
X
X
External fault
Bit
0
1
0.3 X X Channel fault Bit 0 1
0.4
X
X
External auxiliary voltage missing
Bit
0
0
0.5
X
X
Front panel plug missing
Bit
0
0
0.6
X
X
Module not parameterized
Bit
0
0
0.7
X
X
Wrong parameters on module
Bit
0
0
1.0
X
X
Module type
Bit[4]
3
3
1.4
X
X
Channel information available
Bit
1
1
1.5
X
X
Application information available
Bit
0
0
1.6
X
X
Substitute diagnosis alarm
Bit
0
0
1.7
X
X
Reserved = 0
Bit
0
0
2.0
X
X
Application module wrong / missing
Bit
0
0
2.1
X
X
Communication fault
Bit
0
0
2.2
X
X
Operating state (0=RUN, 1=STOP)
Bit
0
0
2.3
X
X
Time monitoring activated
Bit
0
0
2.4
X
X
Supply voltage within module failed
Bit
0
0
2.5
X
X
Battery flat (BATTF)
Bit
0
0
2.6
X
X
Total backup power failed
Bit
0
0
2.7
X
X
Reserved = 0
Bit
0
0
3.0
X
X
Rack failure (detected by IM / UM)
Bit
0
0
3.1 X X Processor failure Bit 0 0
3.2
X
X
EEPROM error
Bit
0
0
3.3 X X RAM error Bit 0 0
3.4
X
X
ADU/DAU error
Bit
0
0
3.5
X
X
Blown fuse
Bit
0
0
3.6
X
X
PRAL missing
Bit
0
0
3.7
X
X
Reserved = 0
Bit
0
0
4.0
X
Channel type
Byte
0x7D
0x7D
5.0
X
Length of the channel-specific diagnostics
Byte
0x20
0x20
6.0
X
Number of channels
Byte
0x01
0x01
7.0
X
Channel fault vector (one bit per channel)
Byte
0x00
0x01
8.0
X
Reserved
Bit
0
0
8.1
X
Short circuit
Bit
0
0
8.2
X
Undervoltage
Bit
0
0
8.3
X
Overvoltage
Bit
0
0
8.4
X
Overload
Bit
0
0
8.5
X
Overtemperature
Bit
0
0

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
