Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
185
3.3.2.13
Data record 132 - Extended device parameters 1
Table 3- 35 Data record 132 - Extended device parameters 1
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Information
0.0
Coordination
Byte[4]
BU0 BU2(+)
4.0
Bit parameters (17)
4.0
3UF50 compatibility mode
Bit
0, 1
0
BU2(+)
4.1 3UF50 operating mode Bit 0, 1 0 0 = DPV0
1 = DPV1
BU2(+)
4.2
Reserved
Bit
0
4.3
Reserved
Bit
0
4.4
Reserved
Bit
0
4.5
Reserved
Bit
0
4.6
Reserved
Bit
0
4.7
Reserved
Bit
0
5.0
Reserved
Bit
0
5.1
Reserved
Bit
0
5.2
OPD - Warnings
Bit
0, 1
0
0 = Do not
display
1 = Display
BU2(+)
5.3 OPD - Faults Bit 0, 1 0 BU2(+)
5.4 Analog module - Measuring range
input
Bit 0, 1 0 0 = 0 - 20mA
1 = 4 - 20mA
AM1
5.5 Analog module - Measuring range
output
Bit 0, 1 0 AM1
5.6
Reserved
Bit
0
5.7 Reserved Bit 0
6.0
Overshooting/undershooting limit 1
Bit
0, 1
0
0 = ">"
(overshooting)
1 = "<"
(undershooting)
BU2(+)
6.1 Overshooting/undershooting limit 2 Bit 0, 1 0 BU2(+)
6.2
Overshooting/undershooting limit 3
Bit
0, 1
0
BU2(+)
6.3
Overshooting/undershooting limit 4
Bit
0, 1
0
BU2(+)
6.4
Line-to-line voltage
Bit
0, 1
0
0 = No, 1 = Yes
BU2(+)
6.5 OPO level Bit 0, 1 0 0 = NO contact
1 = NC contact
BU2(+)
6.6 Positioner response for OPO Bit 0, 1 0 0 = CLOSED
1 = OPEN
BU2(+)
6.7 Star-delta - Transformer mounting Bit 0, 1 0 0 = Delta
1 = In supply
cable
BU0 BU2(+)
7.0
External fault 5 - Type
Bit
0, 1
0
0 = NO contact
1 = NC contact
BU2(+)
7.1
External fault 6 - Type
Bit
0, 1
0
BU2(+)
7.2
Reserved
Bit
0
7.3
Reserved
Bit
0
7.4
Monitoring external fault 5
Bit
0, 1
0
0 = Always
BU2(+)
