Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
219
3.4.1.4
Socket assignment table - analog
This table contains all assignment numbers (No.) of the sockets (analog). You only need
these assignment numbers if you, for example, use a user program to fill data records and
write them back. All inputs for analog data can only process values of type "Word" (2 bytes).
In order to also be able to process values of type "Byte", the following applies: The byte
value is processed as a low byte, the high byte is always 0.
Table 3- 49 Socket assignment table - analog
No.
Designation
Unit
Information
0
Not connected
1
Fixed level
2
Reserved
3 Reserved
4
Timer 1 - Actual value
100 ms
5 Timer 2 - Actual value 100 ms
6
Timer 3 - Actual value
100 ms
7
Timer 4 - Actual value
100 ms
8
Counter 1 - Actual value
9
Counter 2 - Actual value
10
Counter 3 - Actual value
11
Counter 4 - Actual value
12
Counter 5 - Actual value
13
Counter 6 - Actual value
14
Timer 5 - Actual value
100 ms
15
Timer 6 - Actual value
100 ms
16
Max. current I_max
1 % / Is
IM UM(+)
17
Current I_L1
1 % / Is
IM UM(+)
18
Current I_L2
1 % / Is
IM UM(+)
19
Current I_L3
1 % / Is
IM UM(+)
20
Phase unbalance
1 %
IM UM(+)
21
Ground-fault current
1 mA
UM+
22 Internal ground fault - last trip current 1 mA UM+
23
Voltage U_min
1 V
UM(+)
24 Voltage U_L1 1 V see 2) UM(+)
25
Voltage U_L2
1 V see 2)
UM(+)
26
Voltage U_L3
1 V see 2)
UM(+)
27
Cos phi
1 %
UM(+)
28
Frequency
0.01 Hz
UM+
29
Reserved
30
Number of overload trips
IM UM(+)
31
Int. Number of overload trips
IM UM(+)
32
Thermal motor model
2 %
IM UM(+)
33
Time to trip
100 ms
IM UM(+)
