Communication
2.1 PROFIBUS communication
SIMOCODE pro - Communication
16 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
The following figure shows the communication principle and the way data is transmitted
depending on the master and slave operating modes:
Figure 2-2 Communication principle
Fail-safe data transfer via PROFIBUS / PROFIsafe
SIMOCODE pro V as from version
in conjunction with a fail-safe control (F-CPU) and
the SIMOCODE pro expansion module DM-F PROFIsafe supports fail-safe shutdown of
motors by means of data transmission via the PROFIsafe profile.
You will find more information on using this function in the manual SIMOCODE pro fail-safe
digital modules (https://support.automation.siemens.com/WW/view/en/50564852).
