3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
223
3.4.2
PROFINET data records
3.4.2.1
PROFINET data records - general
Data records - overview
Table 3- 51 Data records - overview
Data record
No.
Length [byte]
Description
Read / write
63
200
Analog value recording (Page 226)
Read
67
10
Process image output (Page 226)
Read
69
30
Process image input (Page 227)
Read
72
126 Error buffer (Page 228) Read
73
168
Event memory (Page 228)
Read
92
46
Device diagnostics (faults, warnings, status information) (Page 229)
Read
94
172
Measured values (Page 238)
Read
95
148
Service / statistical data (Page 240)
Read / write
130
92
Basic device parameters 1 (Page 242)
Read / write
131
124
Basic device parameters 2 (Page 248)
Read / write
132
144
Extended device parameters 1 (Page 252)
Read / write
133
100
Extended device parameters 2 (Page 260)
Read / write
134
180
Extended device parameters 1 (Page 263)
Read / write
135
114
Extended device parameters 2 (Page 269)
Read / write
139
200
Labeling (Page 272)
Read / write
140
200
Labeling 2 (Page 273)
Read / write
165
168
Marking (Page 274)
Read / write
224
24
Password protection (Page 274)
Write
Writing / reading data records
Access to data records via the slot and index
● Index: Data record number
