Siemens SIMOCODE pro - Soft Starter with Reversing Contactor

Tables, data records
3.2 Assignment of cyclic receive and send data for predefined control functions
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
141
3.2.14
Soft starter with reversing contactor
Table 3- 17 Assignment of cyclic receive / send data, soft starter with reversing contactor
Cycl. receive data
Bit 0.0 Device parameters → Motor control → Control stations → PLC/PCS [DP] → ON <
Bit 0.1
Device parameters → Motor control → Control stations → PLC/PCS [DP] → OFF
Bit 0.2 Device parameters → Motor control → Control stations → PLC/PCS [DP] → ON >
Bit 0.3
Further function blocks → Standard functions → Test / Reset → Test1 - Input
Bit 0.4
Further function blocks → Standard functions → Emergency start → Emergency start - Input
Bit 0.5
Device parameters → Motor control → Control stations → Mode selector S1
Bit 0.6
Further function blocks → Standard functions → Test / Reset → Reset 1 - Input
Bit 0.7
Not connected
Bit 1.0
Not connected
Bit 1.1
Not connected
Bit 1.2
Not connected
Bit 1.3
Not connected
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 *) (analog value)
Not connected
Cycl. send data
Bit 0.0
Status - ON<
Bit 0.1 Status - Off
Bit 0.2
Status - ON>
Bit 0.3
Event - Prewarning overload (I>115 %)
Bit 0.4
Status - Interlocking time active
Bit 0.5
Status - Remote mode
Bit 0.6
Status - General fault
Bit 0.7 Status - general warning
Bit 1.0
Not connected
Bit 1.1
Not connected
Bit 1.2
Not connected
Bit 1.3
Not connected
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 (analog value)
Maximum current I_max
Byte 4/5 *) (analog value)
Not connected
Byte 6/7 *) (analog value)
Not connected
Byte 8/9 *) (analog value)
Not connected
*) for SIMOCODE pro V / pro S, basic type 1 only
