Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
201
3.3.2.22
Data record 224 - Password protection
Description
● Password protection ON
If the data record is received with this control flag, the password protection is activated
and the password applied. If "Password protection on" applies and the password is not
identical at the time of receipt, the event "Event - Wrong password" is set and no change
will be made.
● Password protection OFF
If the data record is received with this control flag, the password protection is deactivated.
If the password is incorrect, the event "Event - Wrong password" is set and no change is
made.
Table 3- 44 Data record 224 - Password protection
Byte.Bit
Designation
Type
Information
0.0
Reserved
Byte[4]
BU0 BU1 BU2(+)
4.0 Control flag:
0 = Password protection off, 1 = Password protection on
Bit
4.1
Reserved
Bit[31]
8.0
Password
Byte[8]
BU0 BU1 BU2(+)
16.0
Reserved
Byte[8]
