Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
252 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.4.2.12
Data record 132 - Extended device parameters 1
Table 3- 63 Data record 132 - Extended device parameters 1
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Info
0.0
Reserved
Byte[4]
4.0
Bit parameters (17)
4.0
Reserved
4.1 Reserved
4.2
Reserved
Bit
0
4.3
Reserved
Bit
0
4.4
Reserved
Bit
0
4.5
Reserved
Bit
0
4.6
Reserved
Bit
0
4.7
Reserved
Bit
0
5.0
Reserved
Bit
0
5.1 Voltage measuring - Type of
load
Bit 0, 1 0 0 = 3-phase
1 = 1-phase
5.2
OPD - Warnings
Bit
0, 1
0
0 = Do not display
1 = Display
5.3
OPD - Faults
Bit
0, 1
1
5.4
AM1 - Measuring range input
Bit
0, 1
0
0 = 0-20mA
1 = 4-20mA
AM1
5.5 AM1 - Measuring range
output
Bit 0, 1 0 AM1
5.6
Reserved
Bit
0
5.7
Reserved
Bit
0
6.0 Overshooting/undershooting
limit 1
Bit 0, 1 0 0 = ">"
(overshootin g)
1 = "<"
(undershooting)
6.1 Overshooting/undershooting
limit 2
Bit 0, 1 0
6.2 Overshooting/undershooting
limit 3
Bit 0, 1 0
6.3 Overshooting/undershooting
limit 4
Bit 0, 1 0
6.4 Line-to-line voltage Bit 0, 1 0 0 = No
1 = Yes
6.5 OPO level Bit 0, 1 0 0 = NO contact
1 = NC contact
6.6 Positioner response for OPO Bit 0, 1 0 0 = CLOSED
1 = OPEN
6.7 Star-delta - Transformer
mounting
Bit 0, 1 0 0 = Delta
1 = In supply cable
7.0
External fault 5 - Type
Bit
0, 1
0
0 = NO contact
1 = NC contact
7.1
External fault 6 - Type
Bit
0, 1
0
7.2
Reserved
Bit
0
7.3
Reserved
Bit
0
