Siemens SIMOCODE pro Function Manual

Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
314 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.6.2
Identity object
The following information applies to the Identity object of the SIMOCODE pro V EtherNet/IP
device:
● Class code: 0x0001
● Class attributes: 1, 2, 3
● Number of instances: 1
Table 3- 88 Attributes of instance 1 for the Identity object
Attribute ID
Access
Name
Data type
Value / comment
1
Get
Manufacturer
UINT
1251
2 Get Device Type UINT 0x03
3
Get
Product Code
UINT
2000
4 Get Revision STRUCT of Device revision level
Major Revision
USINT
Minor Revision
USINT
5
Get
Device_Status
WORD
Defined in the "Device_Status" definition table below
6
Get
Serial number
UDINT
Device serial number
7
Get
Product Name
SHORT_STRING
SIMOCODE pro V EIP
Table 3- 89 Device_Status definitions for the Identity object
Bit (s)
Query
Definition
0 Ownership 0 = Not owned
1 = Device has an owner
I/O communication is active
Always 0
2 Configured 0 = Device still in delivery state
1 = Configuration changed
3
Reserved
4, 5, 6, 7
Extended device status
Not supported
8
Minor rectifiable fault/error
Not supported
9
Minor non-rectifiable fault/error
Not supported
10 Serious rectifiable fault/error Serious problem with configuration such as module fault, configuring
error, parameterization error, temporary components fault
11
Serious non-rectifiable fault/error
Serious device fault, e.g. basic unit hardware fault
12 - 15
Reserved
Always 0
