Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
315
Table 3- 90
General services for the Identity object
Service code
Available service
Service designation
Description
Class
Instance
0x01
No
Yes
Get_Attributes_All
Supplies contents of all attributes
0x0E
No
Yes
Get_Attribute_Single
Supplies contents of one attribute
Table 3- 91 Class attributes
Attribute ID
Access
Description
Data type
1
Get
Revision
UINT
2
Get
Max Instance
UINT
3
Get
Num of Instances
UINT
