Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
165
3.3.2.8
Data record 92 - Device diagnostics
Table 3- 30 Data record 92 - Device diagnostics
Byte.Bit
Designation
Information
DP
diagnostics *)
Error No. **)
0.0
Reserved
1.0 Status information -
General
Status - General fault BU0 BU1 BU2(+)
1.1
Status - General warning
BU0 BU1 BU2(+)
1.2
Status - Device
BU0 BU1 BU2(+)
1.3
Status - Bus
BU0 BU1 BU2(+)
1.4
Status - PLC/PCS
BU0 BU1 BU2(+)
1.5
Status - Current flowing
IM UM
1.6
Reserved
2.0 Status information -
Receive
Status - ON<< Dependent on the
control function
2.1
Status - ON<
2.2
Status - Off
2.3
Status - ON>
2.4
Status - ON>>
2.5
Status - Start active
BU0 BU1 BU2(+)
2.6 Status - Interlocking time active All reversing starters
and positioners
2.7 Status - Change-over pause
active
Star-delta starter,
Dahlander starter,
pole-changing starter
3.0
Status - Runs in open direction
Dependent on the
control function
3.1
Status - Runs in close direction
3.2
Status - FC
3.3
Status - FO
3.4 Status - TC
3.5
Status - TO
3.6
Status - Cold start (TPF)
BU0 BU1 BU2(+)
M
3.7
Status - OPO
BU2(+)
4.0
Status - Remote mode
BU0 BU1 BU2(+)
4.1 Status information -
Protection
Status - Emergency start
executed
IM UM M
4.2 Status - Cooling down period
active
IM UM M
4.3
Status - Pause time active
IM UM
4.4 Status information -
Miscellaneous
Status - Device check active BU0 BU1 BU2(+)
4.5
Status - Phase sequence 1-2-3
UM
4.6
Status - Phase sequence 3-2-1
UM
4.7
Status - DM-F enabling circuit
DM-F
