Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
166 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation
Information
DP
diagnostics *)
Error No. **)
5.0
Events - Protection
Event - Overload operation
IM UM
5.1 Event - Unbalance IM UM
5.2
Event - Overload
IM UM
5.3
Event - overload + phase failure
IM UM
5.4
Event - Internal ground fault
IM UM
5.5
Event - External ground fault
EM
5.6 Event - Warning ext. ground
fault
EM
5.7
Event - Thermistor overload
Th
6.0
Event - Thermistor short-circuit
Th
6.1
Event - Thermistor open circuit
Th
6.2
Event - TM warning T>
TM MM
6.3
Event - TM trip T>
TM MM
6.4
Event - TM sensor fault
TM MM
6.5
Event - TM out of range
TM MM
6.6
Event - EM+ open circuit
MM EM(+)
1)
6.7
Event - EM+ short-circuit
MM EM(+)
1)
7.0 Events - Level
monitoring
Event - Warning I> IM UM
7.1
Event - Warning I<
IM UM
7.2
Event - Warning P>
UM
7.3
Event - Warning P<
UM
7.4 Event - Warning cos phi< UM
7.5
Event - Warning U<
UM
7.6
Event - Warning 0/4 - 20mA>
AM
7.7
Event - Warning 0/4 - 20mA<
AM
8.0
Event - Trip I>
IM UM
8.1
Event - Trip I<
IM UM
8.2
Event - Trip P>
UM
8.3
Event - Trip P<
UM
8.4
Event - Trip cos phi<
UM
8.5
Event - Trip U<
UM
8.6
Event - trip 0/4 - 20mA>
AM
8.7
Event - trip 0/4 - 20mA<
AM
9.0
Event - Stalled rotor
IM UM
9.1
Events - Protection
Warning - Internal ground fault
UM+
9.2
Reserved
9.3 Events - Level
monitoring
Event - No start permitted BU0 BU1 BU2(+)
9.4
Event - No. of starts >
BU0 BU1 BU2(+)
9.5
Event - Just one start possible
BU0 BU1 BU2(+)
9.6
Event - motor operating hours >
BU0 BU1 BU2(+)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
