Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
167
Byte.Bit
Designation
Information
DP
diagnostics *)
Error No. **)
9.7
Event - Motor stop time >
BU0 BU1 BU2(+)
10.0 Event - Limit 1 BU2(+)
10.1
Event - Limit 2
BU2(+)
10.2
Event - Limit 3
BU2(+)
10.3
Event - Limit 4
BU2(+)
10.4
Events - Miscellaneous
Event - ext. fault 1
BU0 BU1 BU2(+)
10.5
Event - ext. fault 2
BU0 BU1 BU2(+)
10.6
Event - ext. fault 3
BU0 BU1 BU2(+)
10.7
Event - ext. fault 4
BU0 BU1 BU2(+)
11.0
Event - ext. fault 5
BU2(+)
11.1
Event - ext. fault 6
BU2(+)
11.2
Events - FW update
Event - BU FW update active
BU2+
11.3 Event - Module FW update
active
BU2+
11.4 Events - Miscellaneous Event - Analog module open
circuit
AM
11.5 Event - DM-F safety-related
tripping
DM-F
11.6 Event - DM-F - Test
requirement
DM-F
11.7
Reserved
12.0 Events - Time stamp
function
Event - Timestamping function
active + OK
BU2(+)
12.1
Reserved
12.2
Events - Miscellaneous
Event - DM-FL safety ok
DM-FL
12.3 Event - DM-FP PROFIsafe
active
DM-FP
12.4 Events - System
interfaces
Event - Configured operator
panel missing
BU0 BU1 BU2(+)
12.5
Event - Module not supported
BU0 BU1 BU2(+)
12.6
Event - No module voltage
BU2(+)
13.0 Events - Memory
module
Event - Memory module read in BU0 BU1 BU2(+)
13.1 Event - Memory module
programmed
BU0 BU1 BU2(+)
13.2
Event - Memory module erased
BU0 BU1 BU2(+)
13.3
Reserved
13.4 Event - Initialization module
read in
BU0 BU2(+)
13.5 Event - Initialization module
programmed
BU0 BU2(+)
13.6 Event - Initialization module
cleared
BU0 BU2(+)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
