Siemens SIMOCODE pro Function Manual

Tables, data records
3.3 Tables, PROFIBUS data records
SIMOCODE pro - Communication
168 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
Byte.Bit
Designation
Information
DP
diagnostics *)
Error No. **)
13.7 Event - Addressing
plug
Event - Addressing plug read in BU0 BU1 BU2(+)
14.0 Events -
parameterization
Event - startup parameter block
active
BU0 BU1 BU2(+) M
14.1 Event - Parameter changes not
allowed in the current operating
state
BU0 BU1 BU2(+) M
14.2 Event -
Device does not support the re
quired functions
BU0 BU1 BU2(+) M
14.3
Event - Wrong parameter
BU0 BU1 BU2(+)
M
14.4
Event - Wrong password
BU0 BU1 BU2(+)
M
14.5 Event - Password protection
active
BU0 BU1 BU2(+)
14.6
Event - Factory settings
BU0 BU1 BU2(+)
14.7
Event - Parameterization active
BU0 BU1 BU2(+)
15.0 Event - PRM error number
(bytes) **
BU0 BU1 BU2(+)
16.0 Event - DM-FL configuration
mode
DM-FL
16.1 Event - DM-FL actual and set
configuration are different
DM-FL
16.2 Event - DM-FL waiting for start-
up test
DM-FL
16.3
Event - DM FP PRM error
DM-FP
16.4
Reserved
17.0
Warnings - Protection
Warning - Overload operation
IM UM
W
17.1
Warning - Unbalance
IM UM
W
17.2
Warning - Overload
IM UM
W
17.3 Warning - Overload + phase
failure
IM UM W
17.4
Warning - Internal ground fault
IM UM
W
17.5
Warning - external ground fault
EM MM
W
17.6
Reserved
17.7
Warning - Thermistor overload
Th
W
18.0 Warning - Thermistor short
circuit
Th W
18.1 Warning - Thermistor open
circuit
Th W
18.2
Warning - TM warning T>
TM MM
W
18.3
Reserved
18.4 Warning - TM sensor fault TM MM W
18.5
Warning - TM out of range
TM MM
W
18.6
Warning - EM+ open circuit
MM EM+
1)
W
18.7
Warning - EM+ short-circuit
MM EM+
1)
W

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
